• 1U server blade
• 2U server blade
To replace the component, reverse the removal procedure.
Removing and replacing the PCIe riser
Prerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
Procedure
1. Power down the server blade.
2. Remove the server blade from the chassis.
3. For 2U server blade,
remove the top cover.
156 Removal and replacement procedures
