6. Install the NVMe M.2 SSD.
7.
For 2U server blade, do the following:
a.
Install the air bale.
b.
Install the top cover.
8.
Install the server blade in the chassis.
9.
Power up the server blade.
M.2 SSD option
The server blade system board supports NVMe or SATA M.2 SSDs of size 22x42mm or 22x80mm.
Installing the NVMe M.2 SSD
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• T-10 Torx screwdriver
• Philips No.1 screwdriver
• NVMe M.2 SSD modules
Procedure
1.
Power down the server blade.
2. Remove the server blade from the chassis.
3. For 2U server blade, do the following:
28 Hardware options installation
