HPE ProLiant e910

I. Pull back the retention tab and align the PCIe card.
II. Install the PCIe card and secure it with screw.
6.
For 2U server blade, assemble the top cover.
7. For 2U server blade, install the top cover.
8.
Install the server blade in the chassis.
9. Power up the server blade.
NVMe M.2 enablement option
The server blade supports installation of NVMe enablement board. Four NVMe SSDs of size 22x80mm or 22x110mm can be
installed on the NVMe M.2 enablement board.
26 Hardware options installation
