• Firmware Name—The name of the firmware.
• Firmware Version—The version of the firmware.
• Location—The location of the component that uses the listed firmware.
Replacing the active system ROM with the redundant system ROM
Prerequisites
• Host BIOS privilege
• The server supports redundant system ROM.
Procedure
1. Click Firmware & OS Software in the navigation tree.
2.
On the Installed Firmware page, click
next to the Redundant System ROM details.
iLO prompts you to confirm the request.
3.
Click OK.
The change will take eect after the next server reboot.
A server reboot initiated from iLO requires the Virtual Power and Reset privilege.
Updating iLO or server firmware by using the flash firmware feature
You can update firmware from any network client by using the iLO web interface. A signed file is required.
You can also initiate iLO or server firmware updates from the iLO Repository page.
Prerequisites
• The Configure iLO Settings privilege is required for flashing firmware and storing components in the iLO Repository.
• The Recovery Set privilege is required for making an optional update to the System Recovery Set after a successful
firmware update.
• If you want to use the Update Recovery Set feature, a System Recovery Set must exist and contain the component you
want to update.
• If you want to update to iLO 5 version
210 or later, iLO 5 version 140 or later is installed.
Procedure
1. Obtain a server firmware or iLO firmware file.
2. Power
o the server and wait 30 seconds if you will update the Innovation Engine (IE) or Server Platform Services (SPS)
firmware.
3. Click Firmware & OS Software in the navigation tree, and then click Update Firmware.
If the Update Firmware option is not displayed, click the ellipsis icon in the top-right corner of the iLO web interface,
then click Update Firmware.
4. Select the Local file or Remote file option.
5. Depending on the option you selected, do one of the following:
78 Using HPE iLO 5
