Integrated Remote Console features
The Integrated Remote Console (IRC) supports the following features:
• Keyboard actions with the IRC on page 111
• Virtual power IRC features on page 113
• Virtual media IRC features on page 114
• Console capture (.NET IRC) on page 121
•
Screen captures with the IRC on page 123
Keyboard actions with the IRC
Sending a keyboard action with the HTML5 IRC
Prerequisites
• Remote Console privilege
• A license that supports this feature is installed. For information about the available license types and the features they
support, see the licensing documentation at the following website: http://www.hpe.com/support/ilo-docs.
• The Remote Console feature is enabled on the Access Settings page.
Procedure
1.
Click Remote Console & Media in the navigation tree.
The Launch tab displays the remote console launch options.
2.
Start the HTML5 IRC.
3.
Do one of the following:
• Use your client keyboard to press the desired keys.
• To send the Ctrl+Alt+Del action, click the Virtual Keyboard icon
, and then click the CTRL+ALT+DEL keyboard
shortcut.
• To enable or disable the Caps Lock or Num Lock setting, do one of the following:
◦ Press the NumLock or CapsLock key on your client keyboard.
◦ Click the Virtual Keyboard icon
, and then click the CAPS or NUM keyboard shortcut.
Sending a keyboard action with the .NET IRC or Java IRC
Prerequisites
• Remote Console privilege
• A license that supports this feature is installed. For information about the available license types and the features they
support, see the licensing documentation at the following website:
http://www.hpe.com/support/ilo-docs.
• The Remote Console feature is enabled on the Access Settings page.
Using HPE iLO 5 111
