LFF hot-plug drive cabling for controller with standard power supply
Cable color Description
Orange Drive power cable
Blue Mini-SAS cable to controller port 1
LFF hot-plug drive cabling for controller with Flexible Slot power supply
Cable color
Description
Orange Drive power cable
Blue Mini-SAS cable to controller port 1
Cabling 103
