LFF hot-plug drive cabling
LFF hot-plug drive cabling with standard power supply
Cable color Description
Orange Mini-SAS cable with sideband connector
Blue Drive power cable
LFF hot-plug drive cabling with Flexible Slot power supply
Cable color
Description
Orange Drive power cable
Blue Mini-SAS cable with sideband connector
102 Cabling
