HPE ProLiant ML30 Gen10

Fan locations
Fan number Fan type
1 PCI fan (optional)
2 Heatsink fan
3 System fan
Fan mode behavior
The server supports only nonredundant fan mode. If a single fan fails or is missing, the following behaviors are exhibited:
• The health LED flashes amber.
• The operating system performs a graceful shutdown.
Media device screws
There are eight T-15 Torx screws on the front panel. These screws are provided as spare screws for installing media
devices.
20
Component identification
