Item Description
17 x1 SATA port 6
18 Front USB connector
19 Controller backup power connectors
20 Energy pack connector
21 TPM connector
22 System battery
23 Slot 4 PCI3 x8 (4, 1), half-length
1
24 Slot 3 PCI3 x16 (4, 1), full-length
1
25 Slot 2 PCI3 x8 (4, 1), half-length
1
26 Slot 1 PCI3 x16 (16, 8, 4, 1), full-length
1
1
For more information on the expansion slot specifications, see PCI expansion slot definitions.
System maintenance switch descriptions
Position Default Function
S1
1
O
O = iLO 5 security is enabled.
On = iLO 5 security is disabled.
S2 O Reserved
S3 O Reserved
S4 O Reserved
S5
1
O
O = Power-on password is enabled.
On = Power-on password is disabled.
S6
1,
2,
3
O
O = No function
On = Restore default manufacturing settings
S7 O Reserved
S8 — Reserved
S9 — Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
1
To access the redundant ROM, set S1, S5, and S6 to On.
2
When the system maintenance switch position 6 is set to the On position, the system is prepared to restore all configuration settings to
their manufacturing defaults.
12 Component identification
