Cable color Description
Orange Drive power cable
Blue Mini-SAS cable from controller port 1 to drive backplane port 1
Gold Mini-SAS cable from controller port 2 to drive backplane port 2
Energy pack cabling
Controller backup power cabling
106
Cabling
