HPE R/T3000 G2 User Manual

Installation 17
2.
Install the mounting ears on the chassis using the screws provided.
3. With one person on each side, lift the chassis to rail level and slide the chassis on the mounting rails.
4. Attach the chassis to the rack using the supplied screws.
Connecting the battery leads
WARNING: To prevent personal injury from electric shock or damage to the equipment,
remove the battery lead labels, and verify that the ERM circuit breakers are in the Off position.

HPE R/T3000 G2 Specifications

General

Power Capacity	3000 VA
Battery Type	Sealed Lead-Acid (SLA)
Output Power Capacity	2700 Watts
Rack Height	2U
Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Efficiency	Up to 95%
Operating Humidity	0 to 95% non-condensing
Form Factor	Rack/Tower
Interface	USB, Serial
Product Type	UPS
Battery Runtime	Varies by load
Transfer Time	4-6 ms
Operating Temperature	0 to 40°C (32 to 104°F)
Warranty	3 years
Nominal Output Voltage	120 V, 208 V, 230 V
Noise Level	40-50 dB
