HPE R/T3000 G2

Component identification 8
Item LED
description
Load level
1
Self Test
On—The load level is greater than 10%.
2
Battery Fault
On—The load level is greater than 25%.
3
Site Wiring Fault
On—The load level is greater than 50%.
4
Overtemperature
On—The load level is greater than 75%.
5
Overload
On—The load level is greater than 100%.
6
On Bypass
7
On Battery
8
Utility
For more information, see "LED troubleshooting (on page 54)" .
UPS R/T3000 models
UPS model Description
R/T3000 NA and R/T3000j JPN
•
Domestic/Japanese
•
Low-voltage
•
Nondetachable NEMA L5-30 plug
R/T3000h NA and R/T3000h
JPN
•
Domestic
•
High-voltage
•
Nondetachable NEMA L6-20 plug
R/T3000 INT
•
International
•
High-voltage
•
Detachable country-specific plug
R/T3000 NA and R/T3000j JPN rear panel
Item
Description
1
UPS option card
2
USB communications port
3
Serial communications port
4
Load segment circuit breaker
