HPE R/T3000 G2

UPS operations 42
Button Assertion
time
Audible alarm Mode before
assertion
Utility
present ?
Action
On
0.5 seconds
Every 0.5
seconds until the
button is released
Standby
Yes
Energizes the load and
resets the bypass entry
count to 0
Operate
Yes
Resets the bypass entry
count to 0
Auto-Bypass
Yes
Clears the UPS On audible
alarms, resets the bypass
entry count to 0, and
attempts to transfer to
Operate mode
Converter Off
Yes
Clears the UPS On audible
alarms, resets the bypass
entry count to 0, and
attempts to transfer to
Operate mode
Off
3 seconds
Every 0.5
seconds until the
button is released
Operate
Yes
Transfers to Standby mode,
and power to the load
ceases
Standby
Yes
No action
Battery
No
Powers down the UPS, and
power to the load ceases
Auto-bypass
Yes or No
Transfers to Standby mode
or Converter Off mode, and
power to the load ceases
Self Test
0.5 seconds
Any
Yes or No
Silences audible alarms
after 0.5 seconds
3 seconds
Continuously
Any
Yes or No
Initiates a self-test
Battery
Start
0.5 seconds
Any
Yes or No
No action
Battery
Start and
On
3 seconds
Continuously
UPS off
No
Transfers to battery power,
and begins powering the
load
On and Self
Test
3 seconds
Continuously
Any
Yes or No
Enters or exits
Configuration mode
Configuring the UPS
The UPS automatically detects the number of ERMs connected.
In Configure mode, the LED front panel display changes function to enable modification of the UPS
parameters. Each LED is associated with a different parameter.
Available settings P
arameter Associated LED Explanation (when LED is
illuminated)
Nominal voltage
setting
100/204 Nom
Self Test
Nominal output voltage is 100 V for a low
voltage model and 204 V for a high voltage
model
110/220 Nom
Battery Fault
Nominal output voltage is 110 V for a low
voltage model and 220 V for a high voltage
model
120/230 Nom
Site Wiring Fault
Nominal output voltage is 120 V for a low
voltage model and 230 V for a high voltage
model
