HPE XP7

Screen elements Description
Avg Host Port IO The average host port assigned per I/O based on the selected
volume type (S-VOL or P-VOL).
Avg Host Port MB The average host port assigned per MB based on the selected
volume type (S-VOL or P-VOL).
CLPR Usage % The total percentage of CLPR data usage that is configured for
the selected volume type (S-VOL or P-VOL).
Write Pending % The percentage of data pending to be written on an LDEV from
the CLPR that is configured for the selected Volume type (S-VOL
or P-VOL).
Side File % The utilization of the side file shown as a percentage for a CLPR
that is configured for the selected volume based on the volume
type (S-VOL or P-VOL).
MP Blade Util % The average utilization of the MP Blade that is configured for the
selected volume based on the volume type (S-VOL or P-VOL).
NOTE: The MP Blade average utilization data is collected
during the DKC performance data collection. The collection
frequency set for the DKC data collection might be different
from that set for the LDEV data collection.
RG Util % The total utilization of each RAID Group which is configured for
the volume based on the volume type (S-VOL or P-VOL).
Table 22: Port performance data
Screen element Description
Port Port assigned for the Continuous Access activity.
Attribute Provides CA initiator and RCU Target ports.
Avg IO/sec Average I/O rate per second.
Avg MB/sec Average throughput per second.
Agg GB/hour Displays aggregate throughput value for the last collected hour.
Agg GB/day Displays aggregate throughput value for the last collected day.
Agg GB/week Displays aggregate throughput value for the last collected week.
212 Summary view
