hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Operation
HD09-S Series User Manual V1.1 - 25 -
6.2 Shutdown and Operating Status Parameters
HD09-S Inverter in the state of stop / run, press the key to cycle display the stop / run status
parameter.
• Stop status parameter (F18.08 – F18.13): Set frequency, DC bus voltage, AI input voltage,
potentiometer input voltage, input terminal status, output terminal status.
• Operating status parameter (F18.02 – F18.07): Setting frequency (after Acc. and Dec.), set frequency,
output frequency, output voltage, output current, DC bus voltage.
6.3 Keypad Control Operation
In operation under keypad control (F00.11 = 0), the inverter can be started and operated directly with
keypad.
Steps are as follows:
1. Turn on the input power.
2. Set the motor parameters according to the motor nameplate: F08.00 (Rated power), F08.01 (Rated
voltage), F08.02 (Rated current), F08.03 (Rated frequency), F08.04 (Rated speed).
3. Set the operating frequency: F00.13, range 0.00 - 50.00Hz.
4. Set Acc. / Dec. time: F03.01 (Acc. time), F03.02 (Dec. time).
5. Press key (standard) / key (optional), the inverter starts.
6. Press key (standard) / key (optional), the inverter stops.
