Chapter 7 Detailed Function Introduction
7.1 d00: Status Display Parameters
Ref. Code Function Description Setting Range [Default]
d00.00
Series of the inverter
[Actual value]
d00.01
Software version of the control board
[Actual value]
d00.03
Special software version of the control board
[Actual value]
d00.05
Software version of the keypad
[Actual value]
d00.06
Customized series No.
[Actual value]
d00.07
Control mode
[Actual value]
00: V/f contorl without PG. 20: Vector control without PG.
d00.08 Rated current of the inverter (A) [Actual value]
d00.10
Inverter status
[Actual value]
Display the inverter status, as shown in the following table:
Bit3 Bit2 Bit1 Bit0
Unit
Zero speed running
0: In non-zero speed
runing
1: In zero speed
running
Forward / REV
0: Forward
1: Reverse
Bit1: Run / stop
0: Stop
1: Run
Bit0: Inverter fault
0: No fault
1: Fault
Ten
DC braking
0: Non-DC braking
status
1: In DC braking
Reserved
Bit1&Bit0: Acc. / Dec. / constant
00: Constant
11: Constant
01: Acc.
10: Dec.
Hundred
Reserved
Speed limiting value
0: Not in the limiting
1: In the limiting
Reserved
Parameter auto-
tuning
0: No auto-tuning
1: Auto-tuning
Thousand
Reserved Reserved
Current limiting
0: In
1: Not in
Stall overvoltage
0: In
1: Not in
123
d00.11
Master setting frequency source
[Actual value]
0: Keypad set.
1: Terninal set.
2: Communicaiton set.
3: Analogue set.
4: Terminal pulse set.
6: AI1 terminal setting.
10: Keypad potentiometer setting.
11: PID.
12: Multi-speed.
