hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HD09-S Series User Manual V1.1 - 3 -
Chapter 2 Product Information
2.1 Nameplate
Nameplate Label
Name plate label is pasted on right side of the product. Its contents are shown in the following figure.
Power Label
Power label is below the keypad for recognizing the products easily and quickly.
Power label includes motor power and supply voltage. See section 2.2 Rated Value, page 4.
Its contents are shown in the following figure.
MODEL:
HD09-4T0P7G-S
0.75kW
POWER:
3PH 380-460V 3.4A 50/60Hz
INPUT:
1.5kVA 0-460V 2.3A 0-400Hz
OUTPUT:
1.00
Version:
Product model
Motor power
Input specification
Output specification
Software version
Serial number
HD09-4T0P7G-S
Power label
HD09-2S0P7G-S
Power label
Power label
Motor power
Power voltage
