hpmont HD09-S Series User Manual

Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 60 - HD09-S Series User Manual V1.1
Ref. Code Function Description Setting Range [Default]
F16.26 DO terminal output max. pulse frequency 0.01 - 50.00 [10.00kHz]
Defines the DO terminal for the largest output pulse frequency pulse output.
7.15 F17: SCI Communication Parameter
Ref. Code Function Description Setting Range [Default]
F17.00 Data format 0 - 6 [0]
0: 1-8-2 format, no parity, RTU.
• 1-8-2 format indicates that the communication format is: 1 bit start bit, 8 bits data bit, 2 bit stop bit.
1: 1-8-1 format, even parity, RTU.
• 1-8-1 format indicates that the communication format is: 1 bit start bit, 8 bits data bit, 1 bit stop bit.
2: 1-8-1 format, odd parity, RTU.
• 1-8-1 format indicates that the communication format is: 1 bit start bit, 8 bits data bit, 1 bit stop bit.
6: 1-8-1 format, no parity, RTU.
• 1-8-1 format indicates that the communication format is: 1 bit start bit, 8 bits data bit, 1 bit stop bit.
F17.01 Baud rate choice 0 - 8 [3]
0: 1200bps.
1: 2400bps.
2: 4800bps.
3: 9600bps.
4: 19200bps.
5: 38400bps.
6: 57600bps.
7: 76800bps.
8: 115200bps.
F17.02 The machine address 0 - 247 [2]
F17.02 = 0, it is represented as a broadcast address.
F17.03 This machine response time 0 - 1000 [1ms]
The machine response time refers to a communication port of a frequency inverter receiving a frame of
communication data, waiting for the time set by F17.03 to begin processing the received data. During this
waiting period, this communication port will no longer receive communication commands.
F17.04 LAN communication timeout detection time 0.0 - 600.0 [0.0s]
When the time interval between the two returns to the local data continues to exceed F17.04, the E0028
failure (SCI communication timeout) is reported and the inverter continues to run.
• F17.04 = 0, the drive does not detect the communication timeout.
F17.05 Communication error detection time 0.0 - 600.0 [0.0s]
When the communication error occurs more than F17.05, reported E0029 failure (SCI communication error),
the inverter continues to run.
• F17.05 = 0, the inverter does not detect communication error.
