hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 7 Detailed Function Introduction
HD09-S Series User Manual V1.1 - 31 -
Ref. Code Function Description Setting Range [Default]
d00.50 Input terminal status [Actual value]
Input terminal status is displayed. Each bit (binary) of the function parameter represents a different physical
channel, see the table on the right.
• 0: The multi-function input terminal is disconnected from
the corresponding common terminal.
• 1: The multi-function input terminal is connected to the
corresponding common terminal.
1
Bit12 Bit3 Bit2 Bit1 Bit0
AI DI4 DI3 DI2 DI1
1
d00.51 Output terminal status [Actual value]
Display output terminal status. Each bit (binary) of the function parameter represents a different physical
channel, see the table on the right.
• 0: The multi-function output terminal is disconnected
from the corresponding common terminal.
• 1: The multi-function output terminal is connected to the
corresponding common terminal.
1
Bit3 Bit2 Bit1 Bit0
Reserved RLY DO Reserved
1
d00.55 Total time at power-on (h) [Actual value]
d00.56
Total time at operation (h)
[Actual value]
d00.57 High bit of motor total energy consumption (k kW.h) [Actual value]
d00.58
Low bit of motor total energy consumption (kW.h)
[Actual value]
d00.59 High bit of energy consumption at this time running (k kW.h) [Actual value]
d00.60
Low bit of energy consumption at this time running (kW.h)
[Actual value]
d00.61 Present fault [Actual value]
7.2 F00: Basic Parameter
Ref. Code Function Description Setting Range [Default]
F00.01
Control mode selection
0 - 2 [0]
0: V/f control without PG.
• Constant control voltage / frequency ratio.
• Especially suitable for inverters driving sveral electrical machinery's occasion, in order to improve the
current velocity modulation system.
• When V/f control is selected, set the F09 V/f control parameters reasonably to achieve a good control
effect.
2: PG without vector control.
• That is, the speed sensorless vector control method.
• For general purpose variable speed drive with high performance and torque requirements.
• Auto tuning of the motor parameters is required. Correctly set motor nameplate parameters in F08.00 -
F08.04, start motor parameter auto-tuning to obtain the correct motor parameters, and set the vector
control parameters of F10 group to exert excellent vector control effects.
