Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 30 - HD09-S Series User Manual V1.1
Ref. Code Function Description Setting Range [Default]
d00.12 Master setting frequency (Hz) [Actual value]
d00.13
Auxiliary setting frequency (Hz)
[Actual value]
d00.14 Setting frequency (Hz) [Actual value]
d00.15
Reference frequency (after Acc. / Dec.) (Hz)
[Actual value]
d00.16 Output frequency (Hz) [Actual value]
d00.17
Setting RPM (rpm)
[Actual value]
d00.18 Running RPM (rpm) [Actual value]
d00.20
Output voltage (V)
[Actual value]
d00.21 Output current (A) [Actual value]
d00.22
Torqu e setting (%)
[Actual value]
d00.23 Output torque (%) [Actual value]
d00.24
Output power (kW)
[Actual value]
d00.25 DC bus voltage (V) [Actual value]
d00.26
Potentiometer input voltage of the keypad (%)
[Actual value]
d00.27 AI input (%) [Actual value]
Display filtered AI input voltage / current.
When AI selects the voltage input, 0V corresponds to 0.0% and 10V corresponds to 100.0%.
When AI selects current input, 0mA corresponds to 0.0% and 20mA corresponds to 100.0%.
d00.28 AI input (after disposal) (%) [Actual value]
Displays the AI input voltage / current after gain, offset processing.
When AI selects the voltage input, 0V corresponds to 0.0% and 10V corresponds to 100.0%.
When AI selects current input, 0mA corresponds to 0.0% and 20mA corresponds to 100.0%.
d00.35 DI4 terminal pulse input frequency (Hz) [Actual value]
d00.36
AO output (%)
[Actual value]
AO output is displayed.
When AO selects the voltage output, 0.0% corresponds to 0V and 100.0% corresponds to 10V.
When AO selects 0 - 20mA current output, 0.0% corresponds to 0mA and 100.0% corresponds to 20mA.
d00.38
High-speed output pulse frequency (Hz)
[Actual value]
d00.39 Heatsink temperature (°C) [Actual value]
d00.40
Setting line speed
[Actual value]
d00.41 Reference line speed [Actual value]
d00.44
Process PID reference (%)
[Actual value]
d00.45 Process PID feedback (%) [Actual value]
d00.46
Process PID tolerance (%)
[Actual value]
d00.47 Process PID integral item (%) [Actual value]
d00.48
Process PID output (%)
[Actual value]
d00.49 External counting value [Actual value]
