Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 85 -
Chapter 10 Parameter
Property modification:
"
×
": Can not be modified during operation.
"
○
": Can be modified during operation.
"*": The actual parameters can not be changed.
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
d00: Status Display Parameters
d00.00 Series of the inverter Actual *
d00.01
Software version of the
control board
Actual *
d00.03
Special software version of
the control board
Actual *
d00.05
Software version of the
keypad
Actual *
d00.06 Customized series No. Actual *
d00.07 Control mode
00: V/f contorl without PG
20: Vector control without PG
Actual *
d00.08
Rated current of the
inverter
Actual *
d00.10 Inverter status
Unit:
Bit0: Inverter fault
Bit1: Run / stop
Bit2: FWD / REV
Bit3: Zero speed running
Ten:
Bit1&Bit0: Acc. / Dec. / constant
Bit3: DC braking
Hundred:
Bit0: Parameter auto-tuning
Bit2: Speed limiting value
Thousand:
Bit0: Stall overvoltage
Bit1: Current limiting
Actual *
