hpmont HD09-S Series User Manual

Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 62 - HD09-S Series User Manual V1.1
7.16 F18: Display Control Parameter
Ref. Code Function Description Setting Range [Default]
F18.02 Running display parameter 1 setting 0 - 49 [8]
F18.03
Running display parameter 2 setting
0 - 49 [7]
F18.04 Running display parameter 3 setting 0 - 49 [9]
F18.05
Running display parameter 4 setting
0 - 49 [13]
F18.06 Running display parameter 5 setting 0 - 49 [14]
F18.07
Running display parameter 6 setting
0 - 49 [18]
F18.08 Stopping display parameter 1 setting 0 - 49 [7]
F18.09
Stopping display parameter 2 setting
0 - 49 [18]
F18.10 Stopping display parameter 3 setting 0 - 49 [20]
F18.11
Stopping display parameter 4 setting
0 - 49 [19]
F18.12 Stopping display parameter 5 setting 0 - 49 [43]
F18.13
Stopping display parameter 6 setting
0 - 49 [44]
Defines display contents of keypad.
• The operating parameters (F18.02 - F18.07) or the stop parameters (F18.08 - F18.13) can be cycled display
through the key of the keypad.
• Cycle through the keys of the operator keypad.
0: Reserved.
1: Inverter rated current.
3: Inverter status.
• See d00.10 for details.
4: Main set frequency channel.
5: Main set frequency.
7: Set frequency.
8: Setting
frequency (after Acc. and
Dec.).
9: Output frequency.
• The Hz lamp flashes while
running.
10: Set the speed.
11: Running rpm.
• The RPM lamp flashes while
running.
13: Output voltage.
14: Output current.
15: Torque reference.
16: Output torque.
17: Output power.
18: DC bus voltage.
19: Keypad potentiometer input
voltage.
20: AI input voltage.
21: AI input voltage (after
processing).
28: DI4 terminal pulse input
frequency.
29: AO output.
32: Radiator temperature.
33: Set the line speed.
34: Setting line speed.
42: External count value.
43: Input terminal status.
• Bit0-Bit3 corresponds to DI1 -
DI4.
• Bit12 corresponds to AI.
44: Output terminal status.
• Bit0 - Bit2 corresponds to
reserved, DO, RLY.
48: Power-on time accumulated
(hours).
49: Run time accumulated (hours).
F18.15
Max. line velocity
0 - 65535 [1000]
F18.16 Line speed display accuracy 0 - 3 [0]
0: Integer.
1: A decimal.
2: Two decimal places.
3: Three decimal places.
Note: The max. linear velocity must be newly set after the display accuracy is changed.
