Chapter 9 MODBUS Communication Protocol Shenzhen Hpmont Technology Co., Ltd.
- 84 - HD09-S Series User Manual V1.1
9.4.3 Status Parameter (0x33) Address Mapping
The group number (0x33) of the status parameter is mapped to the high byte of Register address. The
index of the group is shown in the following table:
Address Parameter Address Parameter
0x3300 Inverter series 0x331B AI input voltage
0x3301 Control board software version 0x331C AI input voltage (after processing)
0x3303 Control board software non-standard version 0x3323 DI4 terminal pulse input frequency
0x3305 Keypad software version 0x3324 AO output
0x3306 Customized serial number 0x3326 High speed output pulse frequency
0x3307 Motor and control mode selection 0x3327 Heat sink temperature
0x3308 Inverter rated current 0x3328 Setting the linear speed
0x330A Inverter status 0x3329 Setting linear speed
0x330B Main setting frequency channel 0x332C Process PID setting
0x330C Main setting frequency 0x332D Process PID feedback
0x330D Auxiliary setting frequency 0x332E Process PID error
0x330E Setting frequency 0x332F Process PID integral
0x330F
Setting frequency (after acceleration and
deceleration)
0x3330 Process PID output
0x3310 Output frequency 0x3331 External count value
0x3311 Setting speed 0x3332 Input terminal status
0x3312 Running speed 0x3333 Output terminal status
0x3314 The output voltage 0x3337 Power-on time accumulation
0x3315 The output current 0x3338 Running time accumulation
0x3316 Torque setting 0x3339
High bit motor accumulated energy
consumption
0x3317 Output torque 0x333A
Low bit motor accumulated energy
consumption
0x3318 Output Power 0x333B
High bit motor energy consumption of this
time
0x3319 DC bus voltage 0x333C
Low bit motor energy consumption of this
time
0x331A Keypad potentiometer input voltage 0x333D Current error code
