Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 50 - HD09-S Series User Manual V1.1
Ref. Code Function Description Setting Range [Default]
2,3: FWD / REV enable.
DI termials can be set freely for FWD / REV terminal to control frequency converter start-stop, specific see
F15.16.
Only valid under terminal control mode (F00.11 = 1).
4: Three-wire system operation control.
Specific see F15.16.
8: Frequency switched to the simulation.
Effective, frequency setting channel is forced to be switched to the simulation setting.
Frequency set the channel selection priority: Frequency switched to simulation (function 8) > multistage
frequency terminal 1-3 (function 13-15) > F00.10 set frequency set channels.
11: Command switching terminals.
Enable, running command channel is forced to be switched to the terminal running command channel.
Running command channel selection priority: Command switched to the terminal (function 11) > F00.11
set running command channel.
Only valid in stop.
13 - 15: Multistage frequency terminals 1 - 3 (K1 - K3).
Through the logic combination of the terminals, the frequency converter can finally run at any
frequencies defined by the frequency specified channel and the 7-segment frequency.
Set 3 terminal, can realize switching operation control between frequency specified channel and 7
segment frequency.
Set 2 terminal, can realize switching operation control between frequency specified channel and 3
segment frequency.
A terminal is set to switch the frequency determined by the frequency reference channel and multistage
frequency.
See the table below. K1 corresponds to multistage frequency terminal 1, K2 corresponds to multistage
frequency terminal 2, and K3 corresponds to multistage frequency terminal 3.
K3 (No 15) K2 (No 14) K1 (No 13) Frequency setting
0 0 0 F00.10 set frequency
0 0 1 Multiple frequency instruction 1 (F06.00)
0 1 0 Multiple frequency instruction 2 (F06.01)
0 1 1 Multiple frequency instruction 3 (F06.02)
1 0 0 Multiple frequency instruction 4 (F06.03)
1 0 1 Multiple frequency instruction 5 (F06.04)
1 1 0 Multiple frequency instruction 6 (F06.05)
1 1 1 Multiple frequency instruction 7 (F06.06)
