hpmont HD09-S Series User Manual

Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 64 - HD09-S Series User Manual V1.1
Ref. Code Function Description Setting Range [Default]
F19.05 Set the frequency ratio adjustment selection 0 - 2 [1]
F19.06
Set the frequency scaling factor
0.0 - 200.0 [100.0%]
F19.05, F19.06 Define the adjustment method of the set frequency (the frequency after the main set
frequency and auxiliary set frequency are calculated, referred to as the synthesized frequency).
0: Do not adjust.
• Set frequency = Composite frequency.
1: Relative max. output frequency (F00.06) adjustment.
• Setting frequency = Composite frequency + F00.06 × (F19.06 – 100%).
2: Relative to the current frequency adjustment.
• Setting frequency = Composite frequency × F19.06.
Fan control function (F19.07, F19.08)
Ref. Code Function Description Setting Range [Default]
F19.07
Cooling fan control options
0 - 2 [0]
F19.08 Cooling fan control delay time 0.0 - 600.0 [30.0s]
F19.07 defines the control mode of the cooling fan. If there is over-temperature protection, the fan keeps
running.
0: Auto stop mode.
• When the inverter is running and the fan shut downtime reaches the time set by F19.08, if no
overtemperature protection occurs, the fan will stop automatically.
1: Immediate stop mode.
• When the inverter is running, the fan is running and the fan stops immediately after shutdown.
2: The fan is runningwith power on.
• The fan keeps running when the inverter is powered.
