Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual 119
Code Name Range Default Unit Attributes Setting
F10.01
Synchronous motor
rated power
0.2400.0kW
Depend on
controller
model
0.1kW ×
F10.02
Synchronous motor
rated voltage
0Vcontroller rated voltage 1V ×
F10.03
Synchronous motor
rated current
0.0999.9A 0.1A ×
F10.04
Synchronous motor
rated frequency
1.00100.00Hz 19.20Hz 0.01Hz ×
F10.05
Synchronous motor
rated rpm
124000rpm 96rpm 1rpm ×
F10.06
Synchronous motor
stator resistance
0.0009.999Ω 0.000Ω 0.001Ω ×
F10.07
Synchronous motor
quadrature axis
inductance
0.0999.9mH 0.0mH 0.1mH ×
F10.08
Synchronous motor
direct axis inductance
0.0999.9mH 0.0mH 0.1mH ×
F10.09
Synchronous motor
Back EMF
0V controller rated voltage 380V 1V ×
F10.10
Synchronous motor of
angle auto-tuning
0: No action
1: Static auto-tuning
2: Rotation auto-tuning
0 1 ×
F10.11
Synchronous motor
static auto-tuning
voltage setting
0.0100.0%(F10.02) 100.0% 0.1% ×
F10.12
Synchronous motor
initial angle
0.0359.9° 0.0° 0.1° ×
F10.13
Synchronous motor of Z
pulse initial angle
0.0359.9° 0.0° 0.1° ×
F10.14
Synchronous motor
SINCOS encoder C
amplitude
09999 2048 1 ×
F10.15
Synchronous motor
SINCOS encoder C
zero-bias
09999 2048 1 ×
F10.16
Synchronous motor
SINCOS encoder D
amplitude
09999 2048 1 ×
F10.17
Synchronous motor
SINCOS encoder D
zero-bias
09999 2048 1 ×
F10.18F10.20 Reserved
Group F11 PG Parameters (on pages 73
74)
F11.00 HD5L PG card
1: HD-PG2-OC-FD is valid
2: HD-PG6-UVW-FD is valid
3: HD-PG5-SINCOS-FD is
valid
4 1 ×
