HT 400 Series User Manual

400 Series
EN - 16
8. If the instrument detects a
phase-to-neutral voltage or a
phase-to-earth voltage higher
than the limit, the message
reported here to the side is
displayed. Check that the
instrument is not phase-to-
phase connected
AUTO
Ra = ----
Trcd = ----ms
RP-Pe = ----M
High voltage
High voltage detected
30mA 50V 500V
IdN RCD UL VNom
9. The previous anomalous results cannot be saved

HT 400 Series Specifications

General

Type	Digital Multimeter
Diode Test	Yes
Auto Ranging	Yes
Data Hold	Yes
Operating Temperature	0°C to 40°C
DC Current Range	400μA to 10A
AC Current Range	400μA to 10A
Resistance Range	400Ω to 40MΩ
Continuity Test	Yes
Display	LCD, 4000 counts
Measurement Range	As per individual functions
