GSC60
EN - 140
DEFAULT
Description Settings
System type: Not modified
Frequency: Not modified
Clamp type: Not modified
Full scale clamp: Not modified
TV ratio: Not modified
Start recording: Not modified
Stop recording: Not modified
Aggregation time: Not modified
Voltage anomalies recordings: Selezionata
Reference voltage anomalies (Vn): Not modified
High threshold limit for voltage anomalies: Not modified
Low threshold limit for voltage anomalies: Not modified
Harmonic recording: Selected
Selected voltage: V1(Single); V12,V32,V31(3-wires); V1,V2,V3 (4-wires)
Voltage harmonics:
THD%,DC,01,02… 49
Voltage unbalance: Rev%, Zero% (4-wires), Rev% (3-wires)
Voltage frequency: Selected
Selected current I1 (Single); I1,I2,I3 (3-wires); I1,I2,I3,In (4-wires)
Current harmonics
THD%,DC,01,02… 49
Selected powers
P1+, P1-, Q1i+, Q1i-, Q1c+, Q1c-, S1+, S1- (Single)
Pt+, Pt-, P1+, P1-, P2+, P2-,P3+, P3- Qti+, Qti-,Qtc+,Qtc-,Q1i+,
Q1i-,Q1c+,Q1c-,Q2i+,Q2i-,Q2c+,Q2c-,Q3i+,Q3i-,Q3c+,Q3c-
St+,St-, S1+, S1-,S2+,S2-,S3+,S3- (3-wire, 4-wires)
Selected energies
Ea1+, Ea1-, Er1i+,Er1i-,Er1c+,Er1c-,Es1+,Es1- (Single)
Eat+, Eat-, Ea1+, Ea1-, Ea2+, Ea2-,Ea3+, Ea3- Erti+, Erti-
Ertc+,Ertc-,Er1i+,Er1i-,Er1c+,Er1c-,Er2i+,Er2i-,Er2c+,Er2c-
Er3i+,Er3i-,Er3c+,Er3c- Est+,Est-,Es1+, Es1-,Es2+,Es2-
Es3+,Es3- (3-wires, 4-wires)
Selected power factors, cos
Pf1i+,Pf1i-,Pf1c+,Pf1c-,dPf1i+,dPf1i-,dPf1c+,dPf1c- (Single)
Pfti+,Pfti-,Pftc+,Pftc-,Pf1i+,Pf1i-,Pf1c+,Pftc-,Pf2i+,Pf2i-
Pf2c+,Pf2c-,Pf3i+,Pf3i-,Pf3c+,Pf3c-,dPfti+,dPfti-,dPftc+,dPftc-
dPf1i+,dPf1i-,dPf2c+,dPf2c-,dPf3i+,dPf3i-,dPf3c+,dPf3c-
(3-wires, 4-wires)
Table 11: List of standard parameters saved in a DEFAULT typical configuration
