GSC60
EN - 141
Three-phase 4-wires 3-High Leg systems – for USA systems
EN50160
Description Settings
System type: Not modified
Frequency: Not modified
Clamp type: Not modified
Full scale clamp: Not modified
TV ratio: Not modified
Start recording: Not modified
Stop recording: Not modified
Aggregation time: 10min
Harmonic recording:: Selected
Voltage anomalies recording: Selected
Reference voltage anomalies (Vn): Not modified
High threshold limit for voltage anomalies: 10%Vn
Low threshold limit for voltage anomalies: 10%Vn
Selected voltage: V1,V2,V3,V12,V32,V31
Voltage harmonics:
THD%,DC,01,02… 49
Voltage unbalance: Rev%
Voltage frequency: Selected
Selected current Not selected
Selected powers Not selected
Table 12: List of standard parameters saved in a EN50160 typical configuration
HARM.
Description Settings
System type: Not modified
Frequency: Not modified
Clamp type: Not modified
Full scale clamp: Not modified
TV ratio: Not modified
Start recording: Not modified
Stop recording: Not modified
Aggregation time: 10min
Voltage anomalies recording: Selected
Reference voltage anomalies (Vn) Not modified
High threshold limit for voltage anomalies: Not modified
Low threshold limit for voltage anomalies: Not modified
Harmonic recording Selected
Selected voltage: V1,V2,V3, V12,V32,V31
Voltage harmonics:
THD%,DC,01,02… 49
Voltage unbalance: Not selected
Voltage frequency: Selected
Selected current I1,I2,I3,In
Current harmonics:
THD%,DC,01,02… 49
Powers, Energie, power factors Not selected
Table 13: List of parameters saved in HARMONICS typical configuration
