GSC60
EN - 70
9.
For earth resistance measurement in TN systems, in
case of positive result (measured value LOWER than
set limit value), the screen to the side is displayed by
the instrument. It contains also the value of contact
resistance of the voltage probe (Rs) and the value of
contact resistance of the current probe (Rh).
Press the SAVE button or touch the icon to save
the measurement (see § 7.1).
10
For earth resistance measurement in TN systems, in
case of negative result (measured value HIGHER than
set limit value), the screen to the side is displayed by
the instrument. It contains also the value of contact
resistance of the voltage probe (Rs) and the value of
contact resistance of the current probe (Rh).
Note the presence of the measurement result
highlighted in red.
Press the SAVE button or touch the icon to save
the measurement (see § 7.1).
