Item Description
Maximum power
consumption
16.0 W (excluding the output power of the USB port,
IoT card, or PoE_OUT port)
NOTE
The actual maximum power consumption depends on local
laws and regulations.
Environment
specifications
Operating
temperature
l -60 m to +1800 m: -10°C to +50°C
l 1800 m to 5000 m: Temperature decreases by 1°C
every time the altitude increases 300 m.
Storage
temperature
-40°C to +70°C
Operating
humidity
5% to 95% (non-condensing)
IP rating IP41
Atmospheric
pressure
53 kPa to 106 kPa
1.4 Ordering Information
To place an order, contact technical support personnel.
Part Number
Description
50082944 AP4050DN-E Mainframe(11ac wave2,Dual Band,Built-in
Antenna,BT,USB,PSE,IoT Slot)
50083055 AP4050DN-E Mainframe Bundle (AP4050DN-E Mainframe*8)
AP4050DN-E
Hardware Installation and Maintenance Guide
1 Product Overview
Issue 05 (2018-02-02) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
