Huawei AP4050DN-E User Manual

1
2
3
1. AP4050DN-E 2. IoT card 3. M2x7 screws
4. Install RF cables and sort cables following the instruction shown in the figure.
NOTE
l The diagonal size of a hexagon SMA connector must be less than or equal to 8 mm; otherwise, the
cable cannot be installed.
5. Slide the cover back.
2.6 Installing the AP
NOTE
Remove the protective film on the surface before installation to prevent electrostatic discharge.
2.6.1 Installing the Device on a Wall
AP4050DN-E
Hardware Installation and Maintenance Guide
2 AP Installation
Issue 05 (2018-02-02) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
