Usually, the packing list contains the following items.
l AP device
l Sheet metal mounting bracket
l Adjustable buckle
l Expansion screws
l Quick start guide
l Warranty card
l MAC address label
l SN label
NOTE
If a PoE adapter or a DC power adapter is required, you need to purchase it separately. For DC power adapter
models, see 5.9 Power Adaptation Solution.
2.4 Determining the Installation Position
Indoor APs are usually mounted on a wall or ceiling using sheet metal mounting brackets.
The installation position is determined by the site survey. There must be at least 200 mm
clearance between the cabling end of the AP and the wall. Figure 2-2 shows space
requirements.
Figure 2-2 Mounting an AP
≥200 mm
≥200 mm
≥200 mm
≥200 mm
Floor
Celling
Wall
When determining the AP installation position, comply with the following rules:
l Try to reduce the number of obstacles, such as walls, between the AP and user terminals.
AP4050DN-E
Hardware Installation and Maintenance Guide
2 AP Installation
Issue 05 (2018-02-02) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
