Downward Port, Upward Cable
≥50mm
Ķ
≤100mm
ǹ
Upward Port, Upward Cable
≥50mm
Ķ
≤100mm
ǹ
Horizontal Port, Upward Cable
≥50mm
≤100mm
ǹ
Ķ
Bending Radius Requirements
l The bending radius of a 7/8'' feeder must be more than 250 mm, and that of a 5/4'' feeder
must be more than 380 mm.
AP4050DN-E
Hardware Installation and Maintenance Guide
5 Appendix
