Huawei CX600-X2-M Series User Manual

Attribute Description
Interface attributes Determined by the selected SFP+ optical module
Working mode Full-duplex
Standard
compliance
IEEE 802.3ae
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table 4-3 Attributes of 10GBase SFP+ optical modules
Attributes Description
Transmission
distance
0.3 km (0.19
mi.)
10 km (6.21 mi.) 40 km (24.86
mi.)
80 km (49.72
mi.)
Center
wavelength
850 nm 1310 nm 1550 nm 1550 nm
Minimum
transmitting
power
-7.3 dBm -8.2 dBm -4.7 dBm 0 dBm
Maximum
transmitting
power
-1 dBm 0.5 dBm 4.0 dBm 4 dBm
Receiving
sensitivity
-11.1 dBm -12.6 dBm -14.1 dBm -24 dBm
Overload
power
-1.0 dBm 0.5 dBm 0.5 dBm -7 dBm
Optical fiber
type
Multi-mode Single-mode Single-mode Single-mode
Table 4-4 Attributes of 10Gbps SFP+ CWDM optical modules
Attri
butes
Description
Trans
missi
on
distan
ce
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
70km
(43.47
mi.)
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 4 Boards
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
90
