Huawei CX600-X2-M Series - AC Power Cables

Table 5-2 Terminal and cable specifications of the 10 mm^2 (0.02 in.^2) power cable
Item Description
Terminal Naked Crimping Terminal,OT,10mm^2,M6,Tin Plating,Naked Ring
Terminal
Naked Crimping Terminal,OT,10mm^2,M8,Tin Plating,Naked Ring
Terminal
Cable Power Cable,-750V,H07Z-K UL3386,10mm^2,Blue,Low Smoke Zero
Halogen Cable
Power Cable,-450/750V,H07Z-K UL3386,10mm^2,Black,Low Smoke
Zero Halogen Cable
Power Cable,-750V,H07Z-K UL3386,10mm^2,Yellow Green,Low Smoke
Zero Halogen Cable
16 mm^2 ( 0.02 in.^2 ) Power Cable
Table 5-3 describes the specifications of the 16 mm^2 (0.02 in.^2) power cable.
Table 5-3 Terminal and cable specifications of the 10 mm^2 (0.02 in.^2) power cable
Item Description
Terminal Naked Crimping Terminal,OT,16mm^2,M8,Tin Plating,Naked Ring
Terminal
Cable Power Cable,-750V,H07Z-K UL3386,16mm^2,Blue,Low Smoke Zero
Halogen Cable
Power Cable,-450/750V,H07Z-K UL3386,16mm^2,Black,Low Smoke
Zero Halogen Cable
Power Cable,-750V,H07Z-K UL3386,10mm^2,Yellow Green,Low Smoke
Zero Halogen Cable
5.1.2 AC Power Cables
This section describes the structure and technical specifications of the AC-input power cable.
NOTICE
If no special requirements are imposed on power cables, power cables are delivered according
to default configurations. Otherwise, power cables need to be purchased locally. For rules of
selecting power cables, see the corresponding computation formula in Guide to Power
Distribution Design.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
5 Cables
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
134
