Table 5-4 describes the specifications of the AC Power Cables.
Table 5-4 AC Power Cables
Item Description
Cable Type External Suite, Power Cords All Over The World, Class I Equipment
With Connector C13, External Cable Set
Cable Type Power Cable,750V,H07Z-K UL3386,4mm^2,Blue,45A,Low Smoke
Zero Halogen Cable 1 M
Cable Type Power Cable,750V,H07Z-K UL3386,4mm^2,Black,45A,Low Smoke
Zero Halogen Cable
Terminal Naked Crimping Terminal,OT,6mm^2,M6,Tin Plating,Insulated Ring
Terminal,12~10AWG,yellow
Power Connector Power Connector,Easy Power Connector,2Pin,220V,30A,Straight
Female,2.5mm^2-4mm^2 without crimping terminal/
1mm^2-1.5mm^2 with crimping terminal
5.2 Chassis and Cabinet Grounding Cable
This section describes the structure and technical specifications of the chassis and cabinet ground
cable.
5.2.1 Introduction
The chassis and cabinet ground cables are used to ground a chassis and a cabinet. Before the
delivery of a device, ground cables are correctly connected to the front, rear, and side doors of
the cabinet.
5.2.2 Structure
The connector of the chassi and cabinet ground cable is the same as the connector of the DC-
input power cable.
5.2.3 Technical Specifications
Table 5-5 lists the technical specifications of the CX600-X1-M4 and cabinet ground cable..
Table 5-5 Technical specifications of the CX600-X1-M4 and cabinet ground cable
Item Description
PGND cable Terminal Naked Crimping Terminal,OT,6mm^2,M4,Tin
Plating,Naked Ring Terminal
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 5 Cables
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
135
