Indicator/Button Status Description
ACT indicator Green If the indicator is steady green, the NPU is in the
master state.
If the indicator is off, the NPU is in the slave state or
fails to be registered.
OFL button - This button indicates the removal of the NPU. Before
removing the NPU, press and hold the OFL button
for 6s until the OFL indicator comes on. Then, you
can remove the board.
A.3.5 FIC Indicators
Table A-15 describes the indicators on a flexible card.
Table A-15 Description of the buttons and indicators on a flexible card
Indicator/
Button
Status
Description
STAT indicator Green If the indicator is steady green, the flexible
card is working properly.
If the indicator is off, the flexible card is not
powered on or fails to be registered.
Yellow If the indicator is steady yellow, the PIC is
installed in a slot for a HIC and an alarm is
reported or the PIC is not loaded with the
logic.
Red If the indicator is steady red, the hardware of
the flexible card is faulty.
SFP LINK/
ACT
Green If the indicator is steady green, the link is Up.
If the indicator blinks green, data is being
transmitted.
If the indicator is off, the link is Down.
RJ45 LINK/
ACT
Green(LINK) If the indicator is steady green, the link is Up.
If the indicator is off, the link is Down.
Orange(ACT) If the indicator blinks orange, data is being
transmitted.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description A List of Indicators
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
164
