Huawei CX600-X2-M Series - Board Specifications

Item Description
Number of MPU slots 2
Maximum port rate supported by PICs or NPUs 10 Gbit/s
3.1.4 Board Specifications
Type Board Name Silkscreen Print
MPU MPUK CX-MPUK
Network Processing Unit NPU-50
NPU-50-E
NPU-50
NPU-50-E
Network Processing Unit NPU-120
NPU-120-E
NPU-120
NPU-120-E
Physical Interface Card 1-Port 10GBase LAN/WAN-SFP+ +
8-Port 100/1000Base-X-SFP Physical
Interface Card(PIC)
1x10GE-8xGE-
SFP
Physical Interface Card 2-Port 10GBase LAN/WAN-SFP+
Physical Interface Card(PIC)
2x10GE-SFP+
8-Port 100/1000Base-X-SFP Physical
Interface Card(PIC)
8xFE/GE-SFP
8-Port 100/1000Base-RJ45 Physical
Interface Card(PIC)
8xFE/GE-RJ
Physical Interface Card 32-Port E1 Physical Interface Card
(PIC, 75ohm)
32xE1-75
32-Port E1 Physical Interface Card
(PIC, 120ohm)
32xE1-120
16-Port E1 Physical Interface Card
(PIC, 75ohm)
16xE1-75
16-Port E1 Physical Interface Card
(PIC, 120ohm)
16xE1-120
4-Port OC-3c/STM-1c POS-SFP
Physical Interface Card(PIC)
4xSTM1-POS
Physical Interface Card 4-Port Channelized OC-3c/STM-1c
POS-SFP Physical Interface Card
(PIC)
4xSTM1-cPOS
Physical Interface Card 4-Port OC-3c/STM-1c POS-SFP
Physical Interface Card(PIC)
4xSTM1-POS
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 3 CX600-X2-M16 Hardware Description
