A.2 Indicators on the CX600-X2-M8
This section describes the indicators on the CX600-X2-M8.
A.2.1 Fan Module Indicators
Table A-6 describes the indicators on a fan module.
Table A-6 Description of the indicators on a fan module
Indicator Color Description
FAN Green If the indicator is steady green, the fan
module is working properly.
If the indicator is off, the fan module fails
to be unregistered, is not powered on, or
has a hardware fault.
Red If the indicator is steady red, the fan
module is faulty.
A.2.2 Power Module Indicators
The indicators of the PSU are located on the plastic panel. Table A-7 describes the indicators
on a DC PSU.
Table A-7 Description of the indicators on a DC PSU
Indicator Color Description
IN Green If the indicator is steady green, the power input is normal.
If the indicator is off, the device is not supplied with -48
V or -60 V power.
OUT Green If the indicator is steady green, the DC PSU is working
properly and supplies stable power.
If the indicator is off, the DC PSU is switched off or has
a hardware fault.
Red If indicator is steady red, the hardware of the DC PSU
fails, the device is not supplied with -48 V or -60 V power,
or the input voltage is lower or higher than the normal
range.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
A List of Indicators
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
159
