Item Description
Cable type Power Cable,-450/750V,H07Z-K UL3386,6mm^2,oli-
vine
Fireproof class CM
Table 5-6 lists the technical specifications of the CX600-X2-M8 and cabinet ground cable..
Table 5-6 Technical specifications of the CX600-X2-M8 and cabinet ground cable
Item Description
PGND cable Terminal Naked Crimping Terminal,OT,10mm^2,M6,Tin
Plating,Naked Ring Terminal
Cable type Power Cable,-450/750V,H07Z-K UL3386,10mm^2,oli-
vine
Fireproof class CM
5.3 Console Port Cable
This section describes the structure and technical specifications of the console interface cable.
5.3.1 Introduction
The console interface cable is used to connect the console interface on the CX600 to the serial
interface of the console to transmit configuration data of the CX600.
The console interface cable is an 8-core shielded cable. One end of the cable is an RJ45 connector
connected to the console interface on the MPU. The other end has DB9 and DB25 connectors,
either of which is connected to the serial interface on a computer.
5.3.2 Structure
Figure 5-1 shows the structure of a console interface cable. Table 5-7 shows the pin assignment
on the console interface cable.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
5 Cables
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
136
