Parameter Unit Value
1564.5-1577.5
(eSFP-100M~2.67Gbps-
SM1571-80Km)
1584.5-1597.5
(eSFP-100M~2.67Gbps-
SM1591-80Km)
1604.5-1617.5
(eSFP-100M~2.67Gbps-
SM1611-80Km)
Spectral characteristics
Maximum root mean square
(RMS) Spectral Width
nm N/A
Maximum spectral width
(-20dB)
nm 1.0
Minimum side mode
suppression ratio (SMSR)
dB 30
Average transmit optical power
Maximum transmit optical
power
dBm 5
Minimum transmit optical
power
dBm 0
Minimum extinction ratio dB 8.2
Optical receiver
Operating wavelength range nm 1270-1620
Minimum receiver
sensitivity
dBm -28
Overload power dBm -9
Maximum optical channel
cost
dB N/A
Maximum reflection factor dB N/A
D.6 10-Gbit/s SFP+ Optical Module
The 10-Gbit/s SFP+ optical modules can only be used on 10 GE interfaces. The wavelength of
the these 10-Gbit/s SFP+ optical modules can be 850 nm, 1310 nm, or 1550 nm. The transmission
distance ranges from 0.3 km (0.19 mi.) to 40 km (24.86 mi.).
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
D Optical Module
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
200
