Item Specification
Earliest
software
version
V800R005C01
Product Specifications
Table 4-59 lists the product specifications of the 4-Port OC-3c/STM-1c POS-SFP Physical
Interface Card(FIC).
Table 4-59 Product specifications of the 4-Port OC-3c/STM-1c POS-SFP Physical Interface
Card(FIC)
Item Description
Protocol and services PPP, HDLC
Connector type SFP
Reliability and availability Hardware feature: supporting hot swap
NMS Enhanced command-line interface
SNMP and MIB supported
Ambient operating
conditions
Operating temperature: -40°C to +65°C (-40°F to 149°F)
(Optics used may limit the ambient temperature range)
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 5% to 95%
Storage environment Storage temperature: -40°C to +70°C (-40°F to 158°F)
Storage humidity: 0% to 95%
4.12 Auxiliary Flexible Interface Card with 4-Port 100Base-
RJ45(FIC, Supporting 1588v2)
NOTE
The FE interfaces and 1588v2 functions are not supported at present.
Overview
The Boolean value input and output interfaces on the card can be connected to the burglarproof
sensor (on the cabinet door) and smoke sensor to implement on-site ambient monitoring.
The alarm input interface (ALMI) on the AUXQ is used to input four channels (numbered from
1 to 4) of alarm signals. The ALMI interface can be connected to sensors such as the burglarproof
sensor and the smoke sensor on the cabinet door, or to other environment monitoring devices.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
4 Boards
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
125
