A.2.3 MPU Indicators
Table A-8 describes the indicators on an MPU.
Table A-8 Description of the buttons and indicators on the MPU panel
Indicator/
Button
Status
Description
STAT
indicator
Green If the indicator is steady green, the MPU is working properly.
If the indicator blinks green, the MPU is being registered.
If the indicator is off, the MPU is not powered on or fails to
be registered.
Red If the indicator is steady red, the hardware of the MPU is
faulty.
ACT
indicator
Green If the indicator is steady green, the MPU functions as the
master MPU.
If the indicator is off, the MPU functions as the slave MPU or
fails to be registered.
ETH LINK
indicator
Green If the indicator is steady green, the ETH link is Up.
If the indicator is off, the ETH link is Down.
ETH ACT
indicator
Yellow If the indicator blinks yellow, data is being transmitted.
If the indicator is off, no data is being transmitted.
RESET
button
- The button is used for resetting the MPU. Press the RESET
button to reset the MPU.
A.2.4 Forwarding Board Indicators
Table A-9 describes the indicators on an NPU.
Table A-9 Description of the buttons and indicators on the NPU panel
Indicator/Button Status Description
STAT indicator Green If the indicator is steady green, the NPU is working
properly.
If the indicator blinks green, the NPU is being
registered.
If the indicator is off, the NPU is faulty or not
powered on.
