C.1 Interface Attributes of 10Base-TX/100Base-TX/
1000Base-T-RJ45
Table C-1 lists the interface attributes of 10Base-TX/100Base-TX/1000Base-T-RJ45.
Table C-1 Interface attributes of the 10Base-TX/100Base-TX/1000Base-T-RJ45
Attributes Description
Connector type RJ45
Working mode Half-duplex or full-duplex mode
Cable specification Super category 5 Shielded Twisted Pair (STP) cable is
recommended.
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
C.2 Interface Attributes of 1000Base-X-SFP
Table C-2 lists the interface attributes of 1000Base-X-SFP.
Table C-2 Interface attributes of the 1000Base-X-SFP
Attributes Description
Connector type LC/PC
Interface attributes Compliant with the selected SFP optical module. (For the attributes
of SFP modules, see Table C-3 .)
Working mode Full-duplex
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table C-3 Attributes of 1000M SFP optical modules
Attributes Description
Transmission
distance
0.5 km
(0.31 mi.)
10 km (6.21
mi.)
40 km
(24.86 mi.)
80 km
(49.71
mi.)
100 km
(62.14 mi.)
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description C List of Interface Attributes
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
171
