Slot Numb
er
Remarks
19 and 20 2 For MPUs, which are in 1:1 backup.
21 and 22 2 For PSUs, which are in 1+1 backup.
23 1 For the fan frame.
3.1.3 CX600-X2-M16 Specifications
Chassis Specifications
Table 3-5 Physical specifications of the CX600-X2-M16
Item Description
Dimensions (H x W x D) 442 mm x 220 mm x 353 mm (17.4 in. x 8.66 in. x 13.90 in.);
approximately 8 U (352 mm or 13.90 in.) high
Installation Can be installed in an N63B cabinet, a 19-inch standard
cabinet, or a 23-inch rack that complies with the North
American standard
Weight
l DC: 33 kg (72.8 lb)
l AC: 35 kg (77.2 lb)
Typical power consumption 650 W
Heat dissipation 2107 BTU/hour
DC input
voltage
Rated
voltage
-48 V
Maximum
voltage
range
-38 V to -72 V
System
reliability
MTBF
(year)
138.61
MTTR
(hour)
0.5
Ambient
operating
temperature
Long-term 0°C to +45°C (32°F to 113°F), startup at -20°C(-4°F)
Short-term -5°C to +55°C (23°F to 131°F)
(Short-term refers to a period of not more than 96 consecutive
hours and a total of not more than 15 days in 1 year.)
Remarks Temperature change rate limit: 30°C/hour ( 86°F/hour )
