Huawei CX600-X2-M Series User Manual

Table D-33 Specifications of the BIDI-FE 40Km optical modules
Parameter Unit Value
Interface standard - 1000BASE-BX
Transmission rate Mbit/s 125
Interface type - LC
Transmission distance km 40
Optical transmitter
Optical source type DFB
Center wavelength nm 1310/1550
Operating wavelength range nm 1260–1360
1540–1560
Spectral characteristics
Maximum root mean square
(RMS) spectral width
nm N/A
Maximum spectral width
(-20 dB)
nm N/A
Minimum side mode
suppression ratio (SMSR)
dB 30
Average transmit optical
power
Maximum transmit optical
power
dBm 2
Minimum transmit optical
power
dBm –3
Minimum extinction ratio dB 9
Optical receiver
Operating wavelength range nm 1310/1550
Receiver sensitivity dBm –24
Overload power dBm -3
Maximum optical channel
cost
dB N/A
Maximum reflection factor dB N/A
Table D-34 lists the specifications of the BIDI-GE 80Km optical modules.
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
D Optical Module
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
217
