31
Introduce the Interface
The following table shows details.
Parameter Description
Profile List Include all profile name
Profile Name Input the name of the selected or created profile
Dial-up Number Input the character string for PPP dial-up. For details, refer to the
carrier.
PPP User Name The user name used in PPP communication. It is provided by the
network carrier.
PPP Password It refers to the password used in PPP communication. It is provided
by the network carrier.
APN Select the mode for obtaining the APN:
y Dynamic: Obtain the APN dynamically the network
y Static: Enter the APN manually provided by the network carrier
IP Address Select the mode for obtaining the IP address:
y Dynamic: Obtain the IP address dynamically the network
y Static: Enter the IP address manually provided by the network
carrier
Create Profile
1. Input the profile information in the text box according to the interface prompts.
2. Click
to submit the new profile.
Modify Profile
1. Select the profile to be changed in the Profile List draw-down box. Relevant
information is displayed in corresponding text box.
2. Input the Profile parameters.
3. Click
to submit the modified profile.
Delete Profile
1. Select the profile to be deleted in the Profile List draw-down box.
2. Click
to delete chosen profile.
