36
Enable or Disable the AP Isolation
y On: The terminals accessing the gateway through the WLAN cannot communicate with
each other.
y Off: The terminals accessing the gateway through the WLAN can communicate with
each other.
Select the WLAN Channel.
y Country: It is used to identify the country. Different countries have different standards
on channel usage. Each country defines a group of specific channels.
y Channel: It refers to the channel the gateway works with. According to the IEEE802.11
standard, the working frequency range for the wireless LAN based on the Direct
Sequence Spread Spectrum (DSSS) technology is 2.4GHz to 2.4835GHz. The frequency
occupation of each channel is 22MHz.The available channels vary with the selected
country. The default setting is 11. If you do not know which channel to select, please
select Auto and gateway can search channel automatically.
Configure 802.11 Mode
There are four available modes, as shown in the following table.
Mode Description
54g Auto The WLAN has the best compatibility in this mode.
54g Performance The WLAN has the best performance in this mode.
54g LRS If the gateway has some difficulty in communicating with devices
conforming to the IEEE 802.11b standards, please select this
mode.
802.11b Only The gateway can only work with data transfer rates defined by
the 802.11b standard.
Configure the Transfer Rate
Rate: It is used to set the WLAN transfer frequency of the E960. You can set the value to
Auto, the gateway automatically search the rate. The highest data transfer rate of a WLAN
supported by the gateway is 54Mbit/s.
Click
to submit the setting. Click Advanced to configure WLAN
advanced setting.
Advanced Settings for WLAN
You can configure the security and Network Bridge.
To Next Page
