FusionModule800 Smart Small Data Center
Maintenance Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-60 Removing the front cover
Step 2 Remove the inner cover, as shown in Figure 5-61.
Figure 5-61 Removing the inner cover
In the scenario with a SD card, remove the SD card and install to a new camera.
Step 3 Remove the screws securing the camera base from the camera mounting plate, as shown in
Figure 5-62.
